Conventional flow delivery, food and beverage production dosage additives, process fermentation system for acid and alkali defoaming, laboratories, etc.
main feature
Adopt high-torque, maintenance-free brushless DC motor
With speed display, flow display, timing and quantitative functions.
The peristaltic pump can be used to control the speed, start-stop status, and running direction of the peristaltic pump through the external air interface.
With a full-speed button, the pipeline can be quickly filled and emptied.
RS485 communication protocol uses Modbus protocol, which is easy to debug and use.
Front panel display for easy operation
| Flow range | 1.5-40L/min | Speed adjustment range | 30-350rpm |
| Speed resolution | 1rpm | Applicable power supply | Three-phase AC 380±10%, 50/60Hz |
| Power consumption | ≤400W | working environment | 0-40°C. Humidity <80% non-condensing |
| Dimensions | 575X320X270mm | Total Weight | 27kg (without inverter) |
| Protection level | IP55 |
| JS350&KZ48 flow parameters | |||
| Drive model | Applicable hose | range of rotation | Reference flow range (L/min) |
| JS350&KZ48 | 88# | 30-350 | 1.3-15 |
| 92# | 3-40 | ||
